Rocktrix · ATV/UTV Series
ATV/UTV Wheels
Rough trail, rocks, mud. Bring it on.
Eight Matte Black designs in 12, 14 or 15 inch, four bolt patterns and three offsets, plus an RT104 wheel and tire kit. Want to air down? RT104BL adds a beadlock ring in 14x7 and 15x7.
The ATV/UTV Series
The lineup
Eight designs, one finish. Pick a design, then your bolt pattern, size and offset.
RT104BLEight Y-Spoke Mesh Beadlock (ATV)
14" / 15" · 2 bolt patterns
From $172.19Check fitment
Choose options
RT111ATV - Teardrop Multispoke
12" / 14" / 15" · 3 bolt patterns
From $96.89Check fitment
Choose options
RT116ATV - 8 Straight Spokes
12" / 14" / 15" · 4 bolt patterns
From $95.19Check fitment
Choose options
Need help?
Send us your make, model and year before you order. We verify fitment on every order before it ships.
Contact supportNo designs match those filters.
Fit guide
Find your fit
Four numbers decide fit: bolt pattern, bore, size and offset. Get them right and the rest is picking a look.
Bolt pattern and bore.
4x110 | 74, 4x137 | 110, 4x156 | 131 or 5x114.3 | 68 (RT116 ATV). Check front and rear.
4x110 machines: IRS or solid rear axle?
IRS takes the same wheel front and rear. Solid rear axle (SRA) takes front 12x7 ET30, rear 12x7 ET-47 (2+5). The ET-47 rear comes in RT101, RT102 and RT103.
Size and offset.
ET30 = 5+2, ET10 = 4+3, ET-47 = 2+5. All our ATV wheels are 7 inches wide.
Lug thread.
Check the thread pitch on your machine, then pick cone seat lug nuts to match.
Check the list.
Open the fitment list for your bolt pattern and size.
Tires.
We recommend 9" to 11" wide tires for our wheels. Tire size help
Bolt pattern | bore
Size | offset
7 of 8 designs come in 4x110 | 74. Not in 4x110 | 74: RT104BL and the RT104 wheel and tire kit.
Design
Size | offset
Finish
12x7 ET-4712x7 ET3014x7 ET3015x7 ET10
12x7 ET-4712x7 ET3014x7 ET30
12x7 ET-4712x7 ET3014x7 ET3014x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET10
12x7 ET3014x7 ET3015x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET10
Size | offset
All 8 designs come in 4x137 | 110. The RT104 wheel and tire kit is 4x156 | 131 only.
Design
Size | offset
Finish
14x7 ET3015x7 ET10
14x7 ET3015x7 ET10
14x7 ET3014x7 ET1015x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET10
14x7 ET1015x7 ET10
15x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET3015x7 ET10
12x7 ET3014x7 ET3014x7 ET1015x7 ET3015x7 ET10
Size | offset
7 of 8 designs come in 4x156 | 131. Not in 4x156 | 131: RT101. The RT104 wheel and tire kit is also 4x156 | 131.
Design
Size | offset
Finish
12x7 ET1015x7 ET10
12x7 ET1014x7 ET3014x7 ET1015x7 ET10
12x7 ET1014x7 ET3014x7 ET1015x7 ET10
14x7 ET1015x7 ET10
12x7 ET1014x7 ET1015x7 ET10
12x7 ET1014x7 ET3014x7 ET1015x7 ET3015x7 ET10
12x7 ET1014x7 ET3014x7 ET1015x7 ET3015x7 ET10
Size | offset
1 of 8 designs comes in 5x114.3 | 68. RT116 ATV only.
Design
Size | offset
Finish
15x7 ET30
Fitment lists
4x137
4x156
5x114.3
Not on the list? Send us your make, model and year before you order. We verify fitment on every order before it ships.
Lug nuts and more
ATV accessories
Lug nuts are not included. Our wheels take cone (60 degree) seat nuts, and the nut and your socket must be no wider than 23mm (7/8").
Spline lug nuts
Black, closed end, 1.4" tall, socket key included
- M10x1.25, pack of 16$22.49
- 3/8"x24, pack of 16$23.49
- M12x1.25, pack of 20$24.99
- M12x1.5, pack of 20$26.99
Bulge lug nuts
Closed end, 1.25" tall, black or silver
- M10x1.25, pack of 16from $18.99
- 3/8"x24, pack of 16from $19.99
No bulge option in M12x1.25 or M12x1.5.
Also handy
- Digital Tire Pressure Gauge (150 PSI)$8.99
- Tire Repair Kit, 48pcs$24.99
- ATV Beadlock Hardware Kit, 20pc$18.00
- 3mm Beadlock Spacerfrom $30.00
For RT104BL owners. The hardware kit is listed for 14" ATV beadlocks.
Where they ride
Same machine, different jobs.
Here's where our wheels show up.
Trails and woods.
5+2 (ET30) keeps the wheel tucked in, close to stock width, for tight trails, gates and trailers.
Farm and ranch.
Feed runs, fence checks, a rack full of tools. Every design lists a load rating per wheel: 700 lbs (12x7), 800 lbs (14x7), 1,000 lbs (15x7), 1,100 lbs (RT104BL).
Hunting, mud and snow.
Early starts, back roads, quiet field edges. Matte Black on every design. A bigger footprint at lower pressure helps traction. Check fender clearance before going up a tire size.
Dunes and sand. Lower tire pressure gives a bigger footprint, so the tire floats instead of digging. Plan to air down? Look at RT104BL.
FAQ
Questions
How do I know a wheel fits my machine?
Match four things, front and rear, then check the fitment list.
- Bolt pattern and bore: shown on every listing as BOLT PATTERN | BORE.
- Size and offset: shown as SIZE | OFFSET.
- Fitment list: on the product page, or in the fitment lists above.
- We verify fitment on every order before it ships. If we spot a possible issue, our team reaches out before processing.
Questions? Contact support.
What do 5+2, 4+3 and 2+5 mean?
The two numbers are inches, and they add up to the wheel width.
- First number: inside lip to mounting face.
- Second number: mounting face to outside lip.
- On our 7 inch wheels they add up to 7.
- Ours: ET30 = 5+2, ET10 = 4+3, ET-47 = 2+5.
- A bigger first number tucks the wheel in.
My 4x110 ATV has a solid rear axle. What do I order?
Our solid rear axle list uses a different rear wheel.
- Front: 12x7 ET30.
- Rear: 12x7 ET-47 (2+5), in RT101, RT102 and RT103.
- See the 4x110 solid rear axle list.
Not sure which rear end you have? Contact support before you order.
Do the wheels come with lug nuts?
No, lug nuts are sold separately.
- Seat: cone (60 degree).
- Width: no wider than 23mm (7/8"), including your socket.
- Threads we sell: 3/8"x24, M10x1.25, M12x1.25 and M12x1.5.
- Check the thread pitch on your machine first.
What tire width should I run?
We recommend 9" to 11" wide tires for our wheels.
- ATV tire sizes read tire diameter x width x wheel diameter, for example 25x10-12.
What does the beadlock on RT104BL do?
A beadlock wheel mechanically clamps the tire bead to the rim, preventing the tire from unseating during low-pressure off-road driving.
- Daily driving: mount the tire on the standard bead seat.
- Bead thicker than 8mm (5/16")? You may need a spacer.
How much weight can each wheel carry?
Each product page lists a load rating per wheel.
- 12x7: 700 lbs
- 14x7: 800 lbs
- 15x7: 1,000 lbs
- RT104BL: 1,100 lbs
- RT104 wheel and tire kit: 800 lbs each
Shipping and returns?
Free shipping to the lower 48.
- Most orders ship within 1 to 2 business days.
- Returns within 30 days of receipt, new and unused.
- Wheels with tires previously mounted are not eligible.
- Return shipping is on the customer.
