RT117BL Double 8 Spoke Beadlock Wheels

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, straight-on face view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, back side view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, three-quarter front view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, straight-on face view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, back side view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, straight-on face view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, back side view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, straight-on face view

Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, back side view

Rocktrix Offroad Wheels RT117BL Matte Black Beadlock rims - 5 lug holes 360 degree video

Rocktrix Offroad Wheels RT117BL Matte Gunmetal Beadlock rims - 5 lug holes 360 degree video

Rocktrix Offroad Wheels RT117BL Matte Black Beadlock rims - 6 lug holes 360 degree video

Rocktrix Offroad Wheels RT117BL Matte Gunmetal Beadlock rims - 6 lug holes 360 degree video

$299.99

BOLT PATTERN | BORE

5x127 | 71.5

6x135 | 87.1

6x139.7 | 93.1

6x139.7 | 106.1

SIZE & OFFSET (BACKSPACING)

17x9 ET-12 (4.5")

17x9 ET-38 (3.5")

COLOR — Matte Black

Matte Black

Matte Gunmetal

Fitment for this setup

5x127 | 71.5, 17x9 ET-12

Only 3 left. Ships within 1-2 business days
Inventory on the way

Quantity

Important: Tire Bead Thickness

Tires 37" and larger may have thicker beads, requiring beadlock spacers (available separately here) to ensure even pressure during assembly and help prevent premature bolt failure. Please see our Beadlock Instruction Guide for more details.

Important: Check Year/Make/Model in Fitment Guide below

Free Shipping to Lower 48 States

Free Hat or Keychain with any wheel purchase - use code MERCH after adding hat/keychain to cart.

0% Interest for 6 Months, Details at Checkout

[{"id":41817346736151,"title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","option1":"5x127 | 71.5","option2":"17x9 ET-12 (4.5\")","option3":"Matte Black","sku":"V10472","requires_shipping":true,"taxable":true,"featured_image":{"id":32708942037015,"product_id":7418350174231,"position":1,"created_at":"2024-11-25T21:21:28-08:00","updated_at":"2025-04-22T11:12:35-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555","variant_ids":[41817346736151,41817346768919]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","public_title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","options":["5x127 | 71.5","17x9 ET-12 (4.5\")","Matte Black"],"price":29999,"weight":16783,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","id":24874760273943,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817347031063,"title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","option1":"5x127 | 71.5","option2":"17x9 ET-12 (4.5\")","option3":"Matte Gunmetal","sku":"V10473","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052661783,"product_id":7418350174231,"position":5,"created_at":"2024-11-25T21:43:23-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/RT117BL_5H_Gunmetal_Black_Ring_3.jpg?v=1750367806","variant_ids":[41817346932759,41817347031063]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","public_title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","options":["5x127 | 71.5","17x9 ET-12 (4.5\")","Matte Gunmetal"],"price":29999,"weight":16783,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, three-quarter front view","id":24874835116055,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/RT117BL_5H_Gunmetal_Black_Ring_3.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346768919,"title":"5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Black","option1":"5x127 | 71.5","option2":"17x9 ET-38 (3.5\")","option3":"Matte Black","sku":"V10474","requires_shipping":true,"taxable":true,"featured_image":{"id":32708942037015,"product_id":7418350174231,"position":1,"created_at":"2024-11-25T21:21:28-08:00","updated_at":"2025-04-22T11:12:35-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555","variant_ids":[41817346736151,41817346768919]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Black","public_title":"5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Black","options":["5x127 | 71.5","17x9 ET-38 (3.5\")","Matte Black"],"price":29999,"weight":17237,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","id":24874760273943,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346932759,"title":"5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Gunmetal","option1":"5x127 | 71.5","option2":"17x9 ET-38 (3.5\")","option3":"Matte Gunmetal","sku":"V10475","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052661783,"product_id":7418350174231,"position":5,"created_at":"2024-11-25T21:43:23-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/RT117BL_5H_Gunmetal_Black_Ring_3.jpg?v=1750367806","variant_ids":[41817346932759,41817347031063]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Gunmetal","public_title":"5x127 | 71.5 \/ 17x9 ET-38 (3.5\") \/ Matte Gunmetal","options":["5x127 | 71.5","17x9 ET-38 (3.5\")","Matte Gunmetal"],"price":29999,"weight":17237,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 5-lug, three-quarter front view","id":24874835116055,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/RT117BL_5H_Gunmetal_Black_Ring_3.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346801687,"title":"6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","option1":"6x135 | 87.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Black","sku":"V10320","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052825623,"product_id":7418350174231,"position":9,"created_at":"2024-11-25T21:44:08-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806","variant_ids":[41817346801687,41817346834455,41817346867223,41817346998295]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","public_title":"6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","options":["6x135 | 87.1","17x9 ET-12 (4.5\")","Matte Black"],"price":24999,"weight":16601,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","id":24874837377047,"position":11,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346965527,"title":"6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","option1":"6x135 | 87.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Gunmetal","sku":"V10325","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052989463,"product_id":7418350174231,"position":13,"created_at":"2024-11-25T21:44:43-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806","variant_ids":[41817346965527,41817347063831,41817347096599]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","public_title":"6x135 | 87.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","options":["6x135 | 87.1","17x9 ET-12 (4.5\")","Matte Gunmetal"],"price":24999,"weight":16601,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","id":24874839212055,"position":16,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346834455,"title":"6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","option1":"6x139.7 | 93.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Black","sku":"V10319","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052825623,"product_id":7418350174231,"position":9,"created_at":"2024-11-25T21:44:08-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806","variant_ids":[41817346801687,41817346834455,41817346867223,41817346998295]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","public_title":"6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","options":["6x139.7 | 93.1","17x9 ET-12 (4.5\")","Matte Black"],"price":24999,"weight":16601,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","id":24874837377047,"position":11,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817347096599,"title":"6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","option1":"6x139.7 | 93.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Gunmetal","sku":"V10324","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052989463,"product_id":7418350174231,"position":13,"created_at":"2024-11-25T21:44:43-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806","variant_ids":[41817346965527,41817347063831,41817347096599]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","public_title":"6x139.7 | 93.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","options":["6x139.7 | 93.1","17x9 ET-12 (4.5\")","Matte Gunmetal"],"price":24999,"weight":16601,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","id":24874839212055,"position":16,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346867223,"title":"6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","option1":"6x139.7 | 106.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Black","sku":"V10317","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052825623,"product_id":7418350174231,"position":9,"created_at":"2024-11-25T21:44:08-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806","variant_ids":[41817346801687,41817346834455,41817346867223,41817346998295]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","public_title":"6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Black","options":["6x139.7 | 106.1","17x9 ET-12 (4.5\")","Matte Black"],"price":29999,"weight":16375,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","id":24874837377047,"position":11,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817347063831,"title":"6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","option1":"6x139.7 | 106.1","option2":"17x9 ET-12 (4.5\")","option3":"Matte Gunmetal","sku":"V10323","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052989463,"product_id":7418350174231,"position":13,"created_at":"2024-11-25T21:44:43-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806","variant_ids":[41817346965527,41817347063831,41817347096599]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","public_title":"6x139.7 | 106.1 \/ 17x9 ET-12 (4.5\") \/ Matte Gunmetal","options":["6x139.7 | 106.1","17x9 ET-12 (4.5\")","Matte Gunmetal"],"price":28499,"weight":16375,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Gunmetal with black beadlock ring, 6-lug, three-quarter front view","id":24874839212055,"position":16,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26l_gunmetal2.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41817346998295,"title":"6x139.7 | 106.1 \/ 17x9 ET-38 (3.5\") \/ Matte Black","option1":"6x139.7 | 106.1","option2":"17x9 ET-38 (3.5\")","option3":"Matte Black","sku":"V10318","requires_shipping":true,"taxable":true,"featured_image":{"id":32709052825623,"product_id":7418350174231,"position":9,"created_at":"2024-11-25T21:44:08-08:00","updated_at":"2025-06-19T14:16:46-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806","variant_ids":[41817346801687,41817346834455,41817346867223,41817346998295]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 6x139.7 | 106.1 \/ 17x9 ET-38 (3.5\") \/ Matte Black","public_title":"6x139.7 | 106.1 \/ 17x9 ET-38 (3.5\") \/ Matte Black","options":["6x139.7 | 106.1","17x9 ET-38 (3.5\")","Matte Black"],"price":29999,"weight":17055,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 6-lug, three-quarter front view","id":24874837377047,"position":11,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a26h_black_001.jpg?v=1750367806"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":41817346736151,"title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","option1":"5x127 | 71.5","option2":"17x9 ET-12 (4.5\")","option3":"Matte Black","sku":"V10472","requires_shipping":true,"taxable":true,"featured_image":{"id":32708942037015,"product_id":7418350174231,"position":1,"created_at":"2024-11-25T21:21:28-08:00","updated_at":"2025-04-22T11:12:35-07:00","alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","width":1500,"height":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555","variant_ids":[41817346736151,41817346768919]},"available":true,"name":"RT117BL - Double 8 Spoke Beadlock - 5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","public_title":"5x127 | 71.5 \/ 17x9 ET-12 (4.5\") \/ Matte Black","options":["5x127 | 71.5","17x9 ET-12 (4.5\")","Matte Black"],"price":29999,"weight":16783,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"Rocktrix RT117BL double 8 spoke beadlock wheel in Matte Black with polished beadlock ring, 5-lug, three-quarter front view","id":24874760273943,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/rocktrix.com\/cdn\/shop\/files\/rt117bl_a25h_black_001.jpg?v=1745345555"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

RT117BL Double 8 Spoke Beadlock

Wheel Description

Introducing the first of many beadlock wheels in the Rocktrix family. The RT117BL features 2 sets of 8 spokes, blending rugged design with contemporary sensibilities. This industrial-styled design tells passersby that your vehicle means business.

Constructed from heavy duty aluminum that undergoes T6 heat treatment. Beadlock rings are manufactured from forged 6061 aluminum. 5/16" Grade 8 zinc plated hardware.

Popular fitments include Jeep Wrangler, Gladiator, Grand Cherokee; Toyota Tacoma, 4Runner; Ford F150, F-150 Raptor. Refer to the fitment guide below to verify fitment.

With no wheel spacers or hub adapters required, the -12 offset is approximately 2" more aggressive than your factory rims. The -38 offset gives almost 3" more clearance for bigger, wider tires over factory wheels.

Designed for both on-road and off-road driving. For daily driving, mount tires onto the traditional bead seats. For off-road driving, secure tires using the beadlock rings.

Compatible with majority of OEM TPMS sensors; however, new TPMS valve stems may be needed. NOTE: Not compatible with OE TPMS sensors on steel wheels.

NOTE: May not work with OE/Factory Lug Nuts (dependent on vehicle year/make/model). See Lug Nut Compatibility section below, or message us with your vehicle information for assistance.

Warning: Beadlock-secured tires are meant for off-road use only as they are not certified for highway use.

NOTE: For Toyota vehicles, wheels will not fit the OE spare tire carriers.

Vehicle	PCD \| Bore	Size	Offset (Backspace)	Tire Size Options
FORD
2004+ Ford F150, incl. Raptor (6-Lug Trucks Only) 2022+ Ford Bronco Raptor	6x135 \| 87.1	17x9	ET -12 mm (4.5 in)	View Tire Sizes
2019+ Ford Ranger 2021+ Ford Bronco	6x139.7 \| 93.1	17x9	ET -12 mm (4.5 in)	View Tire Sizes
JEEP
2007-2018 Jeep Wrangler JK 2018+ Jeep Wrangler JL 2019+ Jeep Gladiator JT	5x127 \| 71.5	17x9	ET -12 mm (4.5 in)	View Tire Sizes
	5x127 \| 71.5	17x9	ET -38 mm (3.5 in)	View Tire Sizes
TOYOTA / LEXUS
2014-2024 Toyota 4Runner 2016-2023 Toyota Tacoma 2007-2014 Toyota FJ Cruiser 2010-2023 Lexus GX460	6x139.7 \| 106.1	17x9	ET -38 mm (3.5 in)	View Tire Sizes
2002-2024 Toyota 4Runner (Non Manual Locking Hubs) 2001-2023 Toyota Tacoma (6-Lug Only, Non Manual Locking Hubs) 2007-2014 Toyota FJ Cruiser 1999-2006 Toyota Tundra 2001-2007 Toyota Sequoia 2010-2023 Lexus GX460 2003-2009 Lexus GX470	6x139.7 \| 106.1	17x9	ET -12 mm (4.5 in)	View Tire Sizes

Bolt Pattern \| Bore	Size	Offset (Backspacing)	Finish	Wheel Weight	Load Rating
5x127 \| 71.5	17x9	ET -12 (4.5")	Matte Black/ Gunmetal	33 lbs	2500 lbs
5x127 \| 71.5	17x9	ET -38 (3.5")	Matte Black/ Gunmetal	34 lbs	2500 lbs
6x135 \| 87.1	17x9	ET -12 (4.5")	Matte Black/ Gunmetal	32.5 lbs	2500 lbs
6x139.7 \| 93.1	17x9	ET -12 (4.5")	Matte Black/ Gunmetal	32.5 lbs	2500 lbs
6x139.7 \| 106.1	17x9	ET -12 (4.5")	Matte Black/ Gunmetal	32 lbs	2500 lbs
6x139.7 \| 106.1	17x9	ET -38 (3.5")	Matte Black	33.5 lbs	2500 lbs

Vehicle	Lug Nut Thread Size	Lug Nut Options
2019+ Jeep Gladiator JT 2018+ Jeep Wrangler JL (2D/4D) 2015+ Ford F150 2022+ Ford Bronco Raptor	M14x1.5	Shop
2024+ Toyota Tacoma	M14x1.5 ET	Shop
2007-2018 Jeep Wrangler JK (2D/4D)	1/2"x20	Shop
2004-2014 Ford F150	M14x2	Shop
2019+ Ford Ranger 2021+ Ford Bronco	M12x1.5	Shop
2002-2024 Toyota 4Runner 2007-2014 Toyota FJ Cruiser 2001-2023 Toyota Tacoma 1999-2006 Toyota Tundra 2001-2007 Toyota Sequoia 2010-2023 Lexus GX460 2003-2009 Lexus GX470	M12x1.5 ET	Shop

If you plan to use your OE/factory nuts or lug nuts other than what we recommend above, please check the information below to verify compatibility.

1. Lug nuts must be cone / conical / taper seat.
2. Lug nuts and your lug socket must not be thicker/wider than 1.25", or they will not fit in the lug holes of our wheels.

Verify lug nut compatibility: lug nut diameter must be less than 1.25 in (34 mm), and the lug seat must be cone, conical or taper 60 degree

Rocktrix recommends using car wash soap in the same dilution ratio as you would to wash your vehicle. If it's safe for the body of your vehicle, it's safe for your wheels. Do not use harsh chemicals such as brake cleaner, degreaser, or dish soap.

RT117BL

Beadlock installation guide

Important read on how to install and secure bead using beadlock ring, and warnings.

See how to install

Warning:

Beadlock-secured tires are not DOT approved and are designed for off-road use only. Tires must be mounted on the "standard bead seat" for highways.
Installation must be performed by qualified technicians only. Improper installation may result in accident, personal injury and/or death.
TORQUE WRENCH REQUIRED to install beadlock rings. DO NOT PERFORM INSTALLATION without a torque wrench.
Beadlock rings MUST be re-torqued and inspected at least once every 250 miles.
Thoroughly inspect every beadlock and check tire pressure prior to each drive. Do not operate vehicle if any bolts are discovered to be loose or broken.
Failure to do any of the above may result in beadlock bolts breaking, causing sudden deflation of tire, resulting in accident or injury due to loss of vehicle control.

Warning: check tire bead thickness

BEADLOCK BOLTS MAY BREAK IF BEADLOCK RING IS NOT PROPERLY SEATED ON THE WHEEL, RESULTING IN UNEVEN FORCE TO BE APPLIED ON THE BEADLOCK BOLT, EVENTUALLY LEADING TO FAILURE (see illustration below). This is caused by oversized/thicker beads that come with larger tire sizes. A beadlock spacer may be needed (available separately here) in order to properly seat the beadlock ring.

Beadlock ring seating: correct without spacer; incorrect, uneven, not properly seated, spacer required; correct with spacer

Securing bead using standard bead seat/flange

Mount and balance as a normal wheel, using the drop center. A “decorative beadlock ring” (available separately here) is recommended in lieu of the beadlock ring.

Wheel cross-section: Inner Bead Seat, Standard Bead Seat, Beadlock Bead Seat

Securing bead using beadlock ring

Completely remove the beadlock ring and all hardware from the wheel assembly. Set aside.
Install valve stems using the same method as a standard non-beadlock wheel.
Lay the wheel face-up on a flat surface, or on a tire mounting machine.

Apply tire lubricant to the bottom bead of the tire and barrel of the wheel. Begin mounting the tire by placing the tire on the wheel, then push down on alternating corners until the bead drops into the barrel. Ensure the outer/upper bead is seated and centered on the top flange.
Place the beadlock ring on the tire and wheel, then line up the holes. Secure the beadlock ring to the wheel by hand threading the bolt and washer assembly, starting at the 12 o’clock position and using a cross star pattern until all hardware is installed. Ensure the tire remains centered during this process.

Bolt tightening star pattern from START, 1 to 8, for Full Size and ATV / UTV beadlock rings

Once all the hardware is hand tightened, use a torque wrench set to 10-14 ft/lb and repeat the cross tightening pattern.
Repeat the same cross tightening pattern, but with the torque wrench set to 18-24 ft/lb.
Make one final circular pass with the torque wrench, and ensure every bolt is torqued to spec.

Perform a visual check to ensure that the ring is seated flat against the wheel. You may use a feeler gauge to check various areas between the ring and wheel to validate. If you are seeing coning of the ring or notice a gap in any part of the assembly, you may need a beadlock spacer which can be found here.
Seat the rear bead, by inflating the tire until the bead visually or audibly pops into place. NEVER EXCEED MAX PSI LISTED BY TIRE MANUFACTURER
After first drive, retorque all beadlock bolts to 18-24 ft/lbs and re-torque lug nuts to manufacturer recommended specifications.
